Toshiba C55-C User Manual

2. Grasp the disc tray gently and pull until it is fully opened.
Figure 4-2 Pressing the eject button and pulling the disc tray open
1
2
1. Eject button 2. Disc tray
3. Lay the disc, label side up, in the disc tray.
Figure 4-3 Inserting a disc
1
1. Laser lens
When the disc tray is fully opened, the edge of the computer covers the
disc tray slightly. Therefore, you must turn the disc at an angle when you
place it in the disc tray. After seating the disc, however, make sure it lies
flat.
Do not touch the laser lens or any portion of its surrounding casing as
this could cause misalignment.
Prevent foreign objects from entering the drive. Check the surface of
the disc tray, especially the area behind the front edge of the disc tray,
to make sure there are no such objects before closing the drive.
4. Press gently at the center of the disc until you feel it click into place.
The disc should lie below the top of the spindle, flush with the spindle
base.
5. Push the center of the disc tray to close it. Press gently until it locks
into place.
User's Manual
4-7

Toshiba C55-C Specifications

General

Processor	Intel Core i3/i5/i7
RAM	DDR3L
Storage	500 GB / 1 TB HDD or 128 GB SSD
Display	15.6" HD (1366 x 768) or FHD (1920 x 1080)
Graphics	Intel HD Graphics or NVIDIA GeForce
Operating System	Windows 10
Battery	4-cell Lithium-ion
Weight	Approx. 2.2 kg (4.85 lbs)
Optical Drive	DVD SuperMulti Drive
Connectivity	Wi-Fi 802.11ac, Bluetooth 4.0
Ports	USB 3.0, USB 2.0, HDMI, VGA, Ethernet, headphone/microphone combo jack
