75
EN
Introduction Connections
Basic Setup /
TV View Operation
Recording Playback Editing Function Setup Others
Specifications
Note
The specifications and design of this product are subject to change without notice.
General
Power requirements 220–240 V ± 10 %, 50 Hz ± 0.5 %
Power consumption 26 W
Power consumption (standby) 0.74 W
Weight 3.2 kg
Dimensions (width x height x depth) 420 x 59 x 357 mm
Operating temperature 5°C to 40°C
Operating humidity Less than 80 % (no condensation)
TV system PAL-I
Recording
Recording format Video Recording (VR) format (DVD-RW only), video format (DVD-RW, DVD-R),
+VR format (DVD+RW, DVD+R)
Recordable discs DVD-ReWritable, DVD-Recordable, DVD+ReWritable, DVD+Recordable
Video recording format
Sampling frequency
Compression format
13.5 MHz
MPEG
Audio recording format
Sampling frequency
Compression format
48 kHz
Dolby Digital
Tuner
Receivable channels IRA - E69 (For analogue channels)
E21 - E69 (For DVB-T channels)
Input/Output
Front Panel : (AV3/AV4)
Video input
Input level
One RCA connector
1 Vp-p (75 Ω)
S-video input
Input level
One Mini DIN 4-pin jack
Y (luminance) 1 Vp-p (75 Ω)
C (colour) 300 mVp-p (75 Ω)
Audio input
Input level
Two RCA connectors
2 Vrms (input impedance: more than 10 kΩ)
DV input
DV 4-pin jack
IEEE 1394
Rear Panel :
VHF/UHF antenna input/output terminal VHF/UHF set 75 Ω
Audio input /output
Input /output level
Two 21-pin scart sockets (AV1, AV2)
2 Vrms (input impedance: more than 10 kΩ / output impedance: less than 1 kΩ)
Video input /output
Input /output level
Two 21-pin scart sockets (AV1, AV2)
1 Vp-p (75 Ω) each
Component video output
Output level
Three RCA connectors
Y: 1.0 Vp-p (75 Ω)
P
B
/C
B
, P
R
/C
R
: 0.7 Vp-p (75 Ω) each
Audio output
Output level
Two RCA connectors
2 Vrms (output impedance: 680 Ω)
Digital audio output
Output level
One Coaxial pin jack
500 mVp-p (75 Ω)
HDMI output HDMI jack
E7TE0BD_EN.book Page 75 Friday, March 5, 2010 5:08 PM
