4 EDITING FUNCTIONS
156 Image Repeat
Do not place any heavy objects (4 kg (9 lb.) or over) on the original glass and do not press on
it with force.
Breaking the glass could injure you.
5
Key in the read values and specify the repeat count.
1) Press [X1], [X2], [Y1] and [Y2], and then key in the read value correspondingly.
2) Change the number of times you repeat the image (repeat count) by pressing either [ 2] or [ 8].
3) Press [OK].
y The selected area will be copied from the top right corner in a vertical direction.
y If the repeated image runs over the paper size, that part will not be copied.
7
Select other copy modes as required, and then press the [START] button on the control
panel.
4
Read the following 4 values to specify the area using
the left and top scales on the original glass.
X1: From the top left to the left edge of the selected area
X2: From the top left to the right edge of the selected area
Y1: From the top left to the upper edge of the selected area
Y2: From the top left to the lower edge of the selected area
Note that the marks of the original scale have a 2 mm (0.08")
pitch.
6
Place the original again on the original glass with its
face down.
Place with its bottom toward you. Align its top left corner against
that of the original glass.
To Next Page
