Toshiba E-studio2040c - Page 44

Chapter 3 MAINTENANCE / TROUBLESHOOTING
42
1
2
1
Open the front cover of the Finisher, and then pull
out the saddle stitch unit.
11
2 2
2
Take out two empty staple cartridges.
3
1
1
3
2
Take the empty staple case out of the staple
cartridge.
1
2
3
4
Install a new staple case into the staple cartridge
and remove the seal bundling the staples.
1 1
2 2
5
Install two new staple cartridges.
1
2
6
Insert the saddle stitch unit into the Finisher, and
then close the front cover of the Finisher.
Saddle Stitch Unit of Saddle Stitch Finisher (MJ-1106)
