Step Tool
41
Remove the hold button
from the frame.
A view of the P.C. Board
removed.
Phillips
screwdriver
Remove six screws
fixing the P.C. Board.
Phillips
screwdriver
A view of the HDD
removed from the
chassis frame.
Disassembling Procedures
Photo Description Note
Disconnect the cable
from the connector, and
remove the HDD.
Lift up the lock lever of
CN1 and release the
lock.
Remove the P.C. Board.
Remove two screws
from the frame fixing the
P.C. Board.
A view of the P.C. Board
removed from the frame.
23
22
21
27
26
25
24
