5-2. Outdoor Unit (Single phase Type)
HWS-803H-E, HWS-1103H-E, HWS-1403H-E
Control board
(Blue)
(
White)
HMS-1103, 1403H-E only
(White)
(
White)
Upper
(White)
Operating
power
4-way
valve
coil
Reactor
220-230V
50Hz
4F
20SF
Earth screw Earth screw
Earth
screw
Hydro unit
Outdoor unit
Power supply
single phase
(Yellow)
(
White)
(
White)
(
Yellow)
(
White)
(White)(White)(White)
(
White)
WR B
WhiteRed
G
RW B
External
input
Symbol Item name
Compressor Fan motor Pulse motor valve coil Discharge temperature sonsor Suction temperature sensor Heat exchange sensor 1 Heat exchange sensor 2 Outdoor temperature sensor Linetilter 4-way valve coil Compressor case thermostat Fuse 25 A, 250 VAC Fuse 10A, 250 VAC
1. indicates a terminal plate. The number inside indicates the terminal number. 2. The double-dashed line indicates a local wiring while the dashed line indicates
an optional accessory or service wiring.
3. indicates a printed board. 4. For the hydro unit circuit, see the hydro unit wiring diagram.
