WAVEFORMS
H-2
The following waveforms were measured at the point of the corresponding
balloon number in the schematic diagram.
SOUND AMP
IN/OUT
29
NOTE:
30
31
32
36
37
33
34
35
38
39
POWER ON
10µs
2.0V
POWER ON
10µs
2.0V
POWER ON
10µs
2.0V
POWER ON
20µs
0.5V
POWER ON
20µs
2.0V
POWER ON
1ms
100mV
POWER ON
1ms
100mV
DVD PLAY
10µs
0.5V
DVD PLAY
0.5ms
200mV
POWER ON
10ms
0.5V
DVD PLAY
0.5ms
200mV
51
POWER ON
1ms
200mV
50
POWER ON
1ms
200mV
40
STEREO
POWER ON
1ms
50mV
28
STANDBY
0.5µs
50mV
