DVD DECK REPLACEMENT PARTS LIST
Location No. TSB P/N Reference No. Description
! 600 AE005942
A5R801V650
DVD MECHA ASS'Y A5R801V650
601 AE005003
92P100109A
HOLDER,TRAVERSE
602 AE003550
92P100094A
CLAMPER
603 AE003551
92P100088A
GEAR,MOTOR
604 AE003537
92AAA0013A
FEED RACK ASS'Y
605 AE003538
92P200013A
INSULATOR(F)
606 AE003539
92P200014A
INSULATOR(R)
607 AE005929
92SBB0030A
LOADER SUB ASS'Y
608 AE003541
92P100095A
GEAR,PULLEY
609 AE003542
92P100097A
PULLEY,MOTOR
610 AE003549
92P100096A
GEAR,MAIN
611 AE003544
92P200012A
BELT,LOADING
612 AE003545
92P000014A
PLATE,CLAMPER
613 AE003546
92P100093A
RACK,LOADING
614 AE003547
92P100091A
FRAME,MAIN
615 AE004280
92P100100A
TRAY
616 AE003535
92P100089A
RACK,FEED 1
617 AE003536
92P100090A
RACK,FEED 2
618 AE003543
92P300020A
SPRING,RACK FEED
619 BZ710149
800WFAA008
CUSHION C
701 AE003530
811022680U
SCREW,TAP TITE(P) BIND 2.6x8
702 AE003554
814011723U
SCREW,PAN M1.7x2.3 P3
703 AE003555
816112080U
SEMS.TAP TITE(P) PAN W10 2x8
704 AE003556
814011730U
SCREW,PAN M1.7x3 P3
705 AE003557
811022080U
SCREW,TAP TITE(P) BIND 2x8
CD2001 AD301855
122H0O1901
CORD JUMPER 2H0O1901
CD2301 AE003558
122H062102
CORD JUMPER 2H062102
CD2302 AE003559
122H052601
CORD JUMPER 2H052601
! M2602 AE005930
1515S98003
FEED MOTOR BCZ3B03B
! M2603 AE005931
1596S18003
MOTOR,LOADING BCZ3B52B
PCB610 AE005932
A5R801V610
PCB ASS'Y DED003A
PCB640 AE005933
A5R801V640
PCB ASS'Y DED002B
SW1 AE003564
0515S32002
SWITCH SSS-13-2
SW2 AE003565
0500101037
PUSH SWITCH ESE22MH24
J2-1
