ELECTRICAL REPLACEMENT PARTS LIST
Location No. TSB P/N Reference No. Description
DIODES
D802 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D803 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D804 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D805 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D806 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D2201 BZ410087 0021E2Q140 LED LTL-1CHEE-002A
D2303 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D2304 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D3003 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D3005 AE003870 D97U04R31B DIODE,ZENER MTZJ4.3B T-77
D3006 BZ410012 D28TQS04N0 DIODE,SCHOTTKY 11EQS04N-TA1B2
D3007 BZ410021 D97U05R61B DIODE,ZENER MTZJ5.6B T-77
D3008 BZ410012 D28TQS04N0 DIODE,SCHOTTKY 11EQS04N-TA1B2
D3801 BZ410021 D97U05R61B DIODE,ZENER MTZJ5.6B T-77
D3802 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D3803 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D3804 AD300671 D97U01801B DIODE,ZENER MTZJ18B T-77
D3805 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D3806 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D3807 AD300731 D2WXN49370 DIODE,SILICON 1N4937
! D3808 BZ410062 D2WTRM11C0 DIODE,SILICON RM11C-EIC
! D3809 BZ410062 D2WTRM11C0 DIODE,SILICON RM11C-EIC
D3810 AD300671 D97U01801B DIODE,ZENER MTZJ18B T-77
D3811 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D3812 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
! D3815 BZ410062 D2WTRM11C0 DIODE,SILICON RM11C-EIC
! D3816 BZ410062 D2WTRM11C0 DIODE,SILICON RM11C-EIC
! D3817 BZ410010 D28T21DQN9 DIODE,SCHOTTKY 21DQ09N-TA2B1
! D3818 AD300731 D2WXN49370 DIODE,SILICON 1N4937
! D3819 BZ410010 D28T21DQN9 DIODE,SCHOTTKY 21DQ09N-TA2B1
! D3820 BZ410010 D28T21DQN9 DIODE,SCHOTTKY 21DQ09N-TA2B1
! D3821 BZ410126 D2WXRU3AM0 DIODE,SILICON RU3AM-EIC
D3822 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
! D3823 AE006082 D28F0PRA60 DIODE RECTIFIER 30PRA60-FC
! D3824 BZ410010 D28T21DQN9 DIODE,SCHOTTKY 21DQ09N-TA2B1
D3825 AD300070 D97U01201B DIODE,ZENER MTZJ12B T-77
D3826 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D3827 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D3828 BZ410067 D97U02R21B DIODE,ZENER MTZJ2.2B T-77
! D3830 BZ410010 D28T21DQN9 DIODE,SCHOTTKY 21DQ09N-TA2B1
D3831 BZ410064 D97U03R91B DIODE,ZENER MTZJ3.9B T-77
D4001 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D4002 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D4003 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D4004 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D4005 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D8101 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D8111 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D8112 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
ICS
IC101 AE006062 I55D06084A IC OEC6084A
IC103 AD301641 I9UF032310 IC PST3231NR
IC199 AE006461 A5S102U255 INIT DATA BR24L04F-WE2
IC302 AD301983 I01FF58910 IC AN5891SA-E1V
! IC351 AD300056 I0FSP52760 IC AN5276
! IC401 AE002783 I03TD804N0 IC LA78040N-E
IC601 AE004116 I03FC319N0 IC LA76319NM-MPB-E
IC902 BZ611068 I01FF58290 IC AN5829S-E1V
IC905 BZ611104 I0QF02533V IC NJM2533V(TE2)
IC906 BZ611104 I0QF02533V IC NJM2533V(TE2)
IC1501 AE006220 I05FEA45FG IC TC90A45FG
IC2301 AE003581 I03F065650 IC LA6565-TE-L-E
IC2304 AE005769 I07J003580 IC BA10358FV-E2
! IC3001 BZ611015 I1KA97805A IC KIA7805API
! IC3002 BZ611015 I1KA97805A IC KIA7805API
! IC3005 BZ611033 I1KA97809A IC KIA7809API
! IC3800 AE002809 000220002W PHOTO COUPLER PS2561AL1-1-V(W)
IC4001 AE005760 ICQK068620 IC ZR36862PQCG
IC4002 AE005421 I57J0L02F0 IC BR24L02F-WE2
IC4003 AE006061 I07F9E00W0 IC BA33E00WHFP-TR
IC4007 AE006453 S5S101UF01 MEMORY DATA SST39VF800A-70-4C-EKE
J3-2
