2. Outdoor units (Combination of outdoor units)
Corresponding HP 5 HP 6 HP 8 HP 10 HP 12 HP 14 HP 16 HP
MMY- MAP0501HT8 MAP0601HT8 MAP0801HT8 MAP1001HT8 MAP1201HT8 AP1401HT8 AP1601HT8
MMY- MAP0501HT7 MAP0601HT7 MAP0801HT7 MAP1001HT7 MAP1201HT7 AP1401HT7 AP1601HT7
Combined Model
MMY- MAP0501T8 MAP0601T8 MAP0801T8 MAP1001T8 MAP1201T8 AP1401T8 AP1601T8
Cooling capacity (kW) 14.0 16.0 22.4 28.0 33.5 38.4 45.0
Heating capacity (kW) 16.0 18.0 25.0 31.5 37.5 43.0 50.0
5 HP 6 HP 8 HP 10 HP 12 HP 8 HP 8 HP
—————6 HP 8 HP
———————
Combined outdoor units
———————
No. of connectable indoor units 8 10 13 16 20 23 27
Corresponding HP 18 HP 20 HP 22 HP 22 HP 24 HP 24 HP 26 HP
MMY- AP1801HT8 AP2001HT8 AP2201HT8 AP2211HT8 AP2401HT8 AP2411HT8 AP2601HT8
MMY- AP1801HT7 AP2001HT7 AP2201HT7 AP2211HT7 AP2401HT7 AP2411HT7 AP2601HT7
Combined Model
MMY- AP1801T8 AP2001T8 AP2201T8 AP2211T8 AP2401T8 AP2411T8 AP2601T8
Cooling capacity (kW) 50.4 56.0 61.5 61.5 68.0 68.0 73.0
Heating capacity (kW) 56.5 63.0 69.0 69.0 76.5 76.5 81.5
10 HP 10 HP 8 HP 12 HP 8 HP 12 HP 10 HP
8 HP 10 HP 8 HP 10 HP 8 HP 12 HP 8 HP
——6 HP — 8 HP — 8 HP
Combined outdoor units
———————
No. of connectable indoor units 30 33 37 37 40 40 43
Corresponding HP 28 HP 30 HP 32 HP 32 HP 34 HP 34 HP 36 HP
MMY- AP2801HT8 AP3001HT8 AP3201HT8 AP3211HT8 AP3401HT8 AP3411HT8 AP3601HT8
MMY- AP2801HT7 AP3001HT7 AP3201HT7 AP3211HT7 AP3401HT7 AP3411HT7 AP3601HT7
Combined Model
MMY- AP2801T8 AP3001T8 AP3201T8 AP3211T8 AP3401T8 AP3411T8 AP3601T8
Cooling capacity (kW) 78.5 84.0 90.0 90.0 96.0 96.0 101.0
Heating capacity (kW) 88.0 95.0 100.0 100.0 108.0 108.0 113.0
10 HP 10 HP 8 HP 12 HP 10 HP 12 HP 10 HP
10 HP 10 HP 8 HP 10 HP 8 HP 12 HP 10 HP
8 HP 10 HP 8 HP 10 HP 8 HP 10 HP 8 HP
Combined outdoor units
——8 HP — 8 HP — 8 HP
No. of connectable indoor units 47 48 48 48 48 48 48
Corresponding HP 36 HP 38 HP 40 HP 42 HP 44 HP 46 HP 48 HP
MMY- AP3611HT8 AP3801HT8 AP4001HT8 AP4201HT8 AP4401HT8 AP4601HT8 AP4801HT8
MMY- AP3611HT7 AP3801HT7 AP4001HT7 AP4201HT7 AP4401HT7 AP4601HT7 AP4801HT7
Combined Model
MMY- AP3611T8 AP3801T8 AP4001T8 AP4201T8 AP4401T8 AP4601T8 AP4801T8
Cooling capacity (kW) 101.0 106.5 112.0 118.0 123.5 130.0 135.0
Heating capacity (kW) 113.0 119.5 126.5 132.0 138.0 145.0 150.0
12 HP 10 HP 10 HP 12 HP 12 HP 12 HP 12 HP
12 HP 10 HP 10 HP 10 HP 12 HP 12 HP 12 HP
12 HP 10 HP 10 HP 10 HP 10 HP 12 HP 12 HP
Combined outdoor units
— 8 HP 10 HP 10 HP 10 HP 10 HP 12 HP
No. of connectable indoor units 48 48 48 48 48 48 48
