User’s Manual C-3
Wireless LAN
Supported Frequency Sub-bands
Subject to the radio regulations that apply in the countries/regions, your
Wireless LAN module may support a different set of 5 GHz/2.4 GHz
channels. Consult your Authorized Wireless LAN or TOSHIBA Sales office
for information about the radio regulations that apply in the
countries/regions.
2.4GHz Band Channels Sets (Wireless IEEE 802.11 Revision b, g and
n)
*1 Factory-set default channels
*2 The approved channels on using are different at each country or region.
When using these channels in any country or region, refer to the addendum
sheet which is Approved Countries/Regions for use. The channel
configuration is managed as follows:
Frequency Range
Channel ID
2400-2483.5 MHz
1 2412
2 2417
3 2422
4 2427
5 2432
6 2437
7 2442
8 2447
9 2452
10 2457*
1
11 2462
12 2467*
2
13 2472*
2
