User’s Manual G-4
TOSHIBA PC Health Monitor
7. Lift up the back of the keyboard, rotate it toward you and lay in face
down on the palm rest.
Figure G-3 Rotating the keyboard
8. Lift the plastic film and clean the cooling module using a vacuum
cleaner or other cleaning tool.
Figure G-4 Removing the Fan hood
■ Never allow metal objects, such as screws, staples and paper clips, to
enter the computer or keyboard. Foreign metal objects can create a
short circuit, which can cause computer damage and fire, possibly
resulting in serious injury.
■ When you move the keyboard forward, do not touch the keys. Doing so
could cause misalignment. Hold the keyboard by the sides and lay it
gently on the palm rest.
■ The keyboard is connected to the computer by a keyboard ribbon
cable. Be careful not to apply tension to this cable when you lift up the
keyboard. Do not try to disconnect this cable.
1.Keyboard
1. Plastic film
1
2
