User’s Manual 4-10
Operating Basics
2. The disc extends slightly over the sides of the disc tray so you can
grasp it. Gently lift out the disc.
Figure 4-5 Removing a disc
3. Push the center of the disc tray to close it. Press gently until it locks into
place.
How to remove discs when the disc tray will not open
Pressing the eject button will not open the disc tray when the computer
power is off. If the power is off, you can open the disc tray by inserting a
slender object (about 15 mm) such as a straightened paper clip into the
eject hole near the eject button.
Figure 4-6 Manual release with the eject hole
1. Disc tray LED
3. Eject hole
2. Eject button
Slender object about
15mm Diameter 1.0mm
Turn off the power before you use the eject hole. If the disc is spinning
when you open the disc tray, the disc could fly off the spindle and cause
injury.
