User’s Manual 2-4
The Grand Tour
■ Do not connect any cable other than a LAN cable to the LAN jack. It
could cause damage or malfunction.
■ Do not connect the LAN cable to a power supply. It could cause
damage or malfunction.
eSATA/
eSATA/USB Combo
Port
The eSATA/USB combo port supports the USB
2.0 and eSATA functions. Ports with the icon ( )
have USB Sleep and Charge function.
Universal Serial Bus
(USB 2.0) Port
The Universal Serial Bus Port complies with the
USB 2.0 standard.
HDMI Port This port allows you to connect digitally to an
HDTV or home theater receiver.
i.LINK (IEEE1394a)
Port
This port allows you to connect an external
device, such as a digital video camera, for
highspeed data transfer.
(Provided with some models)
ExpressCard Slot This slot allows you to insert an ExpressCard. An
ExpressCard is a small, modular add-in card
technology based on PCI Express and the
Universal Serial Bus (USB) interface. The
maximum transmission rate is 2.5Gbps.
ExpressCard/34 and ExpressCard/54 types are
supported.
Keep foreign metal objects, such as screws, staples and paper clips, out of
the ExpressCard slot. Foreign metal objects can create a short circuit,
which can cause damage and fire, possibly resulting in serious injury.
ODD Indicator
(Tray ODD)
The ODD indicator glows amber when
thecomputer accesses the optical disc drive.
Eject Button (Tray
ODD, Slot ODD)
Press this button to open the ODD tray.
Emergency Eject
Hole (Tray ODD)
In the event that the disc drive becomes
inexplicably locked or stops responding, press
this button to manually eject the ODD tray.
