FILE NO. SVM-08028
4. SPECIFICATION OF ELECTRICAL PARTS
4-1. Indoor Unit
4-2. Outdoor Unit (RAS-07S2AX-1)
Winding resistance (Ω)
C-R C-S
(at 20ºC) 4.84 4.40
Output (Rated) 20 W, 6 poles, 1 phase, 220 - 240 V~, 50Hz
Winding resistance (Ω)
Red-Black White-Black
(at 20ºC) 410 435
Output (Rated) 20 W, 6 poles, 1 phase, 220 - 240 V, 50Hz
Winding resistance (Ω)
Red-Black White-Black
(at 20ºC) 235.2 260.1
Running capacitor
(for fan motor)
Running capacitor
(for compressor)
4 RS44B256U0213S
AC 440 V~, 25µF
5 Overload relay U/T : 4
.2A (80ºC), Open : 135±5ºC, Close : 69±11ºC
DS451155NPQB
AC 450 V~, 1.5µF
3
WLF-240-20A
(Type "A")
SKF-240-20B
(Type "B")
Fan motor (for outdoor)2
Specifications
PH108X1C-4DZDN2 Compressor1
JMRA99208-9102
ST-001
No. Parts name Type Specifications
1 Fan motor (for indoor) AFS-220-20-4AR AC Motor with 145 °C thermo fuse
2 Thermo sensor (TA-sensor) 10k at 25 C
3 Switching power supply (T01)
4 Microcontroller unit (IC30) TMP87CM40ANG-6P68
5 Heat exchanger sensor
10k at 25 C
(TC-sensor)
6 Line filter (L01) LC*SS11V-06270 27mH, 600mA
7 Bridge rectifier (DB01) DB105G 1A, 600 V
8 Capacitor (C27) EKMH401VSN470MP20S 47mF, 400 V
9 Fuse (F01) BET6.3A 6.3A, 250VAC
10 Varistor (R62, R63) SR561K14DL 560 V
11 Resistor (R64)
RF-2TK5R6
5.6 , 2 W
12 Louver motor MP24ZCT 12VDC
13 Relay (Comp., RY01) G4A-1A-E-CA Rating 20A/AC250 V, 12VDC
W
W
W
°
°
Output (Rated) 605W, 2 poles, 1 phase, 220 - 240V~, 50Hz
To Next Page
