Toshiba RAS-13PKVP-E - User Manual

Other manuals for Toshiba RAS-13PKVP-E

Service Manual114 pages

Installation Manual26 pages

Questions and Answers

M
moralesrebeccaAug 7, 2025
What to do if my Toshiba RAS-13PKVP-E Air Conditioner is not turning on?
- A
  Andrea HansenAug 7, 2025
  If your Toshiba Air Conditioner is inoperative, there are several possible reasons. First, ensure that the main power switch is turned on. Also, check if the circuit breaker has been activated, cutting off the power supply, and reset it if necessary. Examine the main power fuse and replace it if it has blown. Verify that there is an electric current. Replace the batteries in the remote controller. If the ON timer is set, disable it. Finally, remember that as a protective measure, the air conditioner may not operate for 3 minutes after restarting or turning on the main power; wait for 3 minutes and try again.
R
Richard SimmonsAug 18, 2025
Why is my Toshiba RAS-13PKVP-E not cooling properly?
- S
  Samantha GrayAug 18, 2025
  If your Toshiba Air Conditioner isn't cooling effectively, several factors could be responsible. Check that the air inlet or outlet of the outdoor unit isn't blocked. Ensure all doors and windows are closed. A clogged air filter can also reduce performance, so clean it. Make sure the louver is correctly positioned. Check that the fan speed isn't set too low, and adjust it as needed. The air conditioner might be in DRY or SLEEP mode, so switch to a more suitable setting. If you are in cooling operation, the temperature setting might be too high, so lower it. Finally, ensure that the air conditioner is being used within its specified operating conditions. If none of these steps work, remove the cause of the problem, and after about 30 seconds, turn on the circuit breaker again.
C
Christopher SmithAug 27, 2025
What to do if my Toshiba Air Conditioner is not heating properly?
- K
  Kenneth MartinezAug 27, 2025
  If your Toshiba Air Conditioner isn't heating effectively, several factors could be responsible. Check that the air inlet or outlet of the outdoor unit isn't blocked. Ensure all doors and windows are closed. A clogged air filter can also reduce performance, so clean it. Make sure the louver is correctly positioned. Check that the fan speed isn't set too low, and adjust it as needed. The air conditioner might be in DRY or SLEEP mode, so switch to a more suitable setting. If you are in heating operation, the temperature setting might be too low, so increase it. Finally, ensure that the air conditioner is being used within its specified operating conditions. If none of these steps work, remove the cause of the problem, and after about 30 seconds, turn on the circuit breaker again.

Summary

Safety Precautions

General Safety Warnings

Important safety instructions including DANGER, WARNING, and CAUTION.

Electrical and Operational Safety

Precautions against electric shock, improper use, and potential hazards.

Environmental and Installation Safety

Safety guidelines related to installation location and environmental factors.

Unit Components and Indicators

Indoor Unit Parts Identification

Identifies and describes parts of the indoor air conditioning unit.

Indoor Unit Display Panel Indicators

Explains the indicators and buttons on the indoor unit's display panel.

Remote Control Operations

Remote Controller Functions Overview

Details the functions of various buttons on the remote controller.

Remote Controller Display Indicators

Understanding Remote Display Symbols

Explains the meaning of indicators shown on the remote controller display.

Initial Setup and Preparation

Remote Controller Battery Installation

Guide on inserting and replacing batteries in the remote controller.

Setting and Adjusting the Remote Clock

Instructions for setting and adjusting the current time on the remote controller.

Using the Remote Controller

Proper Remote Controller Usage

Guidelines for effective and safe use of the remote controller.

Remote Signal Reception and Tones

Information on signal reception, tones, and basic settings.

Operating Modes

Automatic Operation Mode

How the unit automatically selects cooling, heating, or fan operation.

Auto Changeover Operation

Explains automatic cooling/heating selection based on room temperature.

Cooling and Dry Operations

Cooling and Heating Operation Guide

Instructions for performing cooling or heating operations.

Dry Operation Mode

How to use the unit for dehumidification.

Special Operation Modes

8°C Heating Operation (RAS-***-ND)

Function to prevent freezing in unoccupied rooms by maintaining 8°C.

Advanced Operation Features

Pure Operation (Air Purification)

Details on activating and using the air purification function.

High Power (Hi POWER) Operation

How to quickly cool or warm the room for enhanced comfort.

Timer Functions

Setting ON and OFF Timers

Instructions for setting timed start and stop operations.

Combined and Daily Timers

Setting Combined ON;OFF Timers

How to set sequential ON and OFF timers for convenience.

Memory and Comfort Settings

Storing and Using Memory Settings

Guide to storing and recalling preferred operation settings.

Airflow Direction Control

Adjusting Vertical and Horizontal Airflow

How to set the direction of air flow for optimal comfort.

Automatic Airflow Swing Function

Instructions for enabling automatic air louvre swinging.

Automatic Restart Feature

Setting and Canceling Auto Restart

How to enable or disable the automatic restart after power interruption.

Understanding Air Conditioner Operation

How Automatic and Hi POWER Modes Work

Explains the operational logic behind automatic and high power modes.

Sleep Mode and Dry Operation

Details on sleep mode for comfort and dry mode for dehumidification.

Economical Operation and Cleaning

Tips for Economical Usage

Advice on efficient operation to save energy.

Temporary Operation Function

How to operate the unit without the remote controller.

Cleaning Operation Guide

Instructions for the internal cleaning cycle to prevent mold.

Routine Maintenance

Indoor Unit and Remote Controller Cleaning

Procedures for cleaning the indoor unit and remote control.

Long-Term Storage Procedures

Steps for preparing the unit for periods of non-use.

Air Filter Cleaning

Guidance on cleaning the air filters for optimal performance.

Operation Performance and Conditions

Protection Features and Characteristics

Explains protection features, preheating, and defrosting.

Operating Temperature and Humidity Limits

Specifies the recommended operating conditions for the unit.

Troubleshooting Common Issues

Unit Inoperability and Performance Issues

Solutions for when the unit does not start or performs poorly.

Non-Defect Phenomena

Condensation, Noise, and Odor Explanations

Clarifies normal occurrences like condensation, noises, and smells.

Airflow and Mist Behavior

Explains changes in airflow and mist generation during operation.

Indicator and Sound Explanations

PURE Indicator and Operational Sounds

Explains the PURE indicator and various operational sounds.

Remote Controller Troubleshooting

Remote Controller Operation Errors

Addresses issues like incorrect mode switching or unresponsive buttons.

Display and Signal Receiving Issues

Solutions for display errors and lack of signal reception tones.

Technical Specifications

Toshiba RAS-13PKVP-E Specifications

General

Type	Split System
Cooling Capacity	3.5 kW
Heating Capacity	4.0 kW
Energy Efficiency Ratio (EER)	3.21
Refrigerant	R410A
Power Supply	220-240V, 50Hz
Coefficient of Performance (COP)	3.61
Indoor Unit Dimensions (HxWxD)	275x790x205 mm
Indoor Unit Weight	9 kg
Outdoor Unit Weight	30 kg
Outdoor Unit Noise Level	50 dB(A)
