Toshiba RAS-16NAV-E - Outdoor Unit Construction View

– 15 –
FILE NO. SVM-05027
3-2.Outdoor Unit
52
R15
R5.5
36
Service port
Gas side
(Flare ∅9.52 : For
Liquid side
(Flare ∅6.35)
Electrical
part cover
B Detail drawing (Front Leg)
B
600 or more
A Detail drawing (Back Leg)
600
32.5
115 125
310
302
530
265
120
75
54
310 302
∅6 Hole
∅436
270
600
780
90
310
330
62
∅30 Drain outlet
FAN GUARD
Z View
600
310
Installation dimension
100 or more
600 or more
Air outlet
Air inlet
100 or more
4 x ∅11 x 14 Long holes (For ∅8 − ∅10 anchorbolt)
Z
COVER PV
∅6 Hole
R15
36
52
310
102
302
∅11 x 14 Hole
2-∅11 x 14 Hole
(For ∅8-∅10 anchor bolt)
A
RAS-13NAV-E,NAV-A)
(Flare ∅ 12.7 : For
RAS-16NAV-E,NAV-A)
