PARTS NAME
Air inlet (Side and rear)
Pipes and electric wires
Outdoor unit
Air outlet
Indoor unit
Connecting duct
Supply air grille
NOTE :
Parts marked with indicate
the locally prepared parts.
Remote controller
220V/230V 240V
220V 230V
AB
AUTO RESTART
OFF ON
TEMPORARY
COOL AUTO
VOLTAGE1
VOLTAGE2 REMOCON
XXX
Supply chamber
Transmitting section
Receiving section
Air filter
Return grille
Air filter
