*1 … Refer to the service manual of the outdoor unit to be combined.
*2 … Electrical charasteristics in usual use is under FAN ONLY mode HH tap at 10Pa. (M07, 10, 13, 16 type at 35Pa, M22, 24 type at 10Pa)
*3 … Electrical charasteristics in NP is under maximum load condition.
*4 … Air Flow is under standard external static pressure line at each pressure setting.
*5 … Sound power level = Sound pressure level + 15 [dBA]
*6 … Measuring condition of sound pressure level with back air intake:
Air discharge duct length= 2m, air suction duct length=1m, positon of sound pressure level measurement is at 1.4m below the product.
*7 … Measuring condition of sound pressure level with under air intake:
Air discharge duct length= 2m, air suction duct is not attached, positon of sound pressure level measurement is at 1.4m below the product.
*8 … Unit external dimensions (except hanging hook)
Model Name
RAS-M22U2DVG-E RAS-M24U2DVG-E
RAS-M22U2DVG-TR RAS-M24U2DVG-TR
Cooling capacity (Rated) [kW] 6.0 7.1
Cooling Capacity range [kW] *1 *1
Heating Capacity (Rated) [kW] 7.0 8.1
Heating Capacity range [kW] *1 *1
Power supply 1Phase, 50Hz, 220-240V / 1Phase, 60Hz, 220V
Electric characteristics in
usual use *2
Voltage [V] 220 230 240 220 230 240
Running current [A] 0.49 0.47 0.45 0.54 0.52 0.49
Power Consumption [W] 69 76
Power Factor [%] 64 64
Electric characteristics in
NP *3
Maximum current [A] 0.9 0.9
Maximum power input [W] 114 119
External Static Pressure Setting 4steps (10 / 20 / 35 / 45)
10Pa 20Pa 35Pa 45Pa 10Pa 20Pa 35Pa 45Pa
Air flow [m3/h]
*4
Cooling
HH 1000 1060
H+ 940 990
H 870 910
L+ 810 840
L 740 760
Heating
HH 1000 1060
H+ 940 990
H 870 910
L+ 810 840
L 740 760
Sound
pressure
level
[dBA] *5
Cooling
HH 37 37 38 38 38 38 39 39
H+ 36 36 37 37 36 37 37 39
H 3334353634353637
L+ 32 32 34 34 33 33 34 35
L 3031323231323334
Heating
HH 37 37 38 38 38 38 39 39
H+ 36 36 37 37 36 37 37 39
H 3334353634353637
L+ 32 32 34 34 33 33 34 35
L 3031323231323334
Cooling
HH 43 44 45 45 45 45 46 46
H+ 42 43 44 44 44 43 44 46
H 4041424241424244
L+ 38 39 40 41 39 40 41 42
L 3738394038384041
Heating
HH 43 44 45 45 45 45 46 46
H+ 42 43 44 44 44 43 44 46
H 4041424241424244
L+ 38 39 40 41 39 40 41 42
L 3738394038384041
Fan Unit
Fan centrifugal fan
Motor Output [W] 94
Dimensions *8
Height [mm] 210
Width [mm] 1100
Depth [mm] 450
Net weight [kg] 22
Piping connection
Type Flare connection
Liquid side [mm] Φ6.35
Gas side [mm] Φ12.7
Drain port VP25
Usable indoor temperature range
(Cooling / Heating)
21~32°C / 0~28°C
Refrigerant
R410A RAS-M***G3DV*
R32 or R410A RAS-M**U2DVG*
Back air intake *6
Under air intake *7
