Toshiba S15 - Digital Inputs Operation

© Toshiba International Corporation 2021 www.toshiba.com/tic Email: TIC-ASD@toshiba.com (855) 803-7089 13131 West Little York Road, Houston, TX
STEP A
Startup Checklist
Digital Inputs
□ Verify digital input operation
The S15 has seven digital inputs available and one Safe Torque O (STO) input. Four of the digital inputs
can have more than one function assigned. Digital inputs can be monitored on the keypad in Monitor
Mode, refer to S15 Application Note 1.1.0 Navigating Menus & Parameters.
Terminal F
(Default - Forward Run)
Function
Parameters
f111 f151 f155
Assigned Function
Terminal R
(Default - Reverse Run)
Function
Parameters
f112 f152 f156
Assigned Function
Terminal RES
(Default - Reset)
Function
Parameters
f113 f153
N/A
Assigned Function
Terminal S1
(Default - Preset Speed 1)
Function
Parameters
f114 f154
N/A
Assigned Function
Function
Parameters
f115 f116 f117
Assigned Function
Terminal S2
(Default - Preset Speed 2)
Terminal S3
(Default - Preset Speed 3)
Terminal VIB/S4
(Default - Preset Speed 4)
16: Preset Speed Bit 4
0: No Function
0: No Function
4: Reverse Run
0: No Function
0: No Function
8: Reset
0: No Function
10: Preset Speed Bit 1
0: No Function
16: Preset Speed Bit 4
12: Preset Speed Bit 2
14: Preset Speed Bit 3
