Toshiba TCB-IFCG1TLE - Terminal Details

TCS-NET General Purpose Interface
Installation Manual
Toshiba
–19–
EN
Terminal
name
Input/output name
Use and devices to be
connected
Remarks
AI3+ CH1 thermistor
input
(TCB-
IFCG1TLE only)
Analog Input
CH1
Thermistor: Use the YSI’s
product (5 Kohms) or
equivalent
Values converted to Celsius temperature can
be read to one decimal place through the
Modbus (TCB-IFMB640TLE) interface.
AI3- AI3 GND
AI4+ CH2 thermistor
input
(TCB-
IFCG1TLE only)
Analog Input
CH2
Thermistor: Use the YSI’s
product (5 Kohms) or
equivalent
Values converted to Celsius temperature can
be read to one decimal place through the
Modbus (TCB-IFMB640TLE) interface.
AI4- AI4 GND
AI5+ 0-10 V DC input Analog Input
CH3
0 to 10 V. For general
sensors
The buffer output is
connected.
Allocation of the Modbus (TCB-IFMB640TLE)
input register (R)
Values up to the third decimal place can be
transmitted.
AI5- AI5 GND
AI6+ 0-10 V DC input Analog Input
CH4
0 to 10 V. For general
sensors
The buffer output is
connected.
Allocation of the Modbus (TCB-IFMB640TLE)
input register (R)
Values up to the third decimal place can be
transmitted.
AI6- AI6 GND
AO2+ 0-10 V DC
output
(TCB-
IFCG1TLE only)
Analog Output
CH1
0 to 10 V. For general
actuators and input buffers
Connected to the buffer
input, resistance load, etc.
Allocation of the Modbus (TCB-IFMB640TLE)
holding register (R/W)
Values up to the third decimal place can be
transmitted.
AO2- AO2 GND
AO3+ 0-10 V DC
output
(TCB-
IFCG1TLE only)
Analog Output
CH2
0 to 10 V. For general
actuators and input buffers
Connected to the buffer
input, resistance load, etc.
Allocation of the Modbus (TCB-IFMB640TLE)
holding register (R/W)
Values up to the third decimal place can be
transmitted.
AO3- AO3 GND
18-EN
