Toshiba TDP-EW25 User Manual

Extreme Short throw Projector
TDP-EW25
Installation Guide -Ceiling and Desktop mount-
Copyright
©
2007 TOSHIBA CORPORATION, All Rights Reserved.
Projection Distance and screen size for ceiling mount
Ceiling Mount Installation
Distance Chart
Diagonal
inches
41
50
60
70
80
90
100
110
120
Width(H)
mm(inch)
883(34.8)
1077(42.4)
1292(50.9)
1508(59.4)
1723(67.8)
1939(76.3)
2154(84.8)
2369(93.3)
2585(101.8)
Height(V)
mm(inch)
552(21.7)
673(26.5)
808(31.8)
942(37.1)
1077(42.4)
1212(47.7)
1346(53.0)
1481(58.3)
1615(63.6)
B
mm(inch)
276(10.9)
337(13.2)
404(15.9)
471(18.5)
538(21.2)
606(23.8)
673(26.5)
740(29.1)
808(31.8)
degrees
29.0
28.7
28.5
28.3
28.2
28.1
28.0
27.9
27.9
Screen Size (16:10)
C
mm(inch)
498(19.6)
615(24.2)
744(29.3)
874(34.4)
1005(39.5)
1135(44.7)
1265(49.8)
1396(54.9)
1526(60.1)
Ceiling Mount Ctr
Screen Ctr
Screen Top
Lens Ctr
Basic installation plane
for Mount Bracket
63.19
123
102.5
Lens Top
Product Ctr
Lens Ctr
B
C
*1 Please prepare the bracket by user-side, and refer to the drawing of page 5.
*1
