Toshiba TDP-EW25 - TOSHIBA TDP-EW25 Desktop Setup; Desktop Setup and Distances

Extreme Short throw Projector
TDP-EW25
Installation Guide -Ceiling and Desktop mount-
Copyright
©
2007 TOSHIBA CORPORATION, All Rights Reserved.
Projection Distance and screen size for Desktop
Desktop Setup
Distance Chart
Diagonal
inches
41
50
60
70
80
90
100
110
120
Width(H)
mm(inch)
883(34.8)
1077(42.4)
1292(50.9)
1508(59.4)
1723(67.8)
1939(76.3)
2154(84.8)
2369(93.3)
2585(101.8)
Height(V)
mm(inch)
552(21.7)
673(26.5)
808(31.8)
942(37.1)
1077(42.4)
1212(47.7)
1346(53.0)
1481(58.3)
1615(63.6)
B
mm(inch)
276(10.9)
337(13.2)
404(15.9)
471(18.5)
538(21.2)
606(23.8)
673(26.5)
740(29.1)
808(31.8)
degrees
29.0
28.7
28.5
28.3
28.2
28.1
28.0
27.9
27.9
Screen Size (16:10)
C
mm(inch)
498(19.6)
615(24.2)
744(29.3)
874(34.4)
1005(39.5)
1135(44.7)
1265(49.8)
1396(54.9)
1526(60.1)
Screen Ctr
Screen Btm
Lens Ctr
Desktop
102.5
Lens Top
Product Ctr
Lens Ctr
C
66.29
B
