Figure 3-6 The front of the computer with the display panel open
1. Wireless communication antennas
(not shown)*
8. Power button
2. Microphone* 9. Display hinges
3. Microphone* 10. Keyboard
4. Web Camera* 11. Touch Pad
5. Web Camera LED* 12. Touch Pad control buttons
6. Display screen 13. Fingerprint Sensor*
7. Stereo speakers
* Provided with some models.
Product appearance depends on the model you purchased.
Wireless
communication
antennas
Depending on the configuration of your
computer, one or all of the following antennas are
built-in:
Wireless LAN
Wireless LAN/Bluetooth
Some models are equipped with wireless
communication antennas.
Do not cover the wireless communication antennas area with any metal
objects, otherwise the wireless function might not work.
Legal Footnote (Wireless LAN)
For more information regarding Wireless LAN, refer to the Legal Footnotes
section.
User's Manual 3-9
