Docking port This port enables connection of an optional
TOSHIBA Hi-Speed Port Replicator III 180W/
120W described in TOSHIBA Hi-Speed Port
Replicator III 180W/120W.
Some models are equipped with the docking
port.
Only the TOSHIBA Hi-Speed Port Replicator III 180W or 120W is
compatible with the docking port.
Do not attempt to use any other Port Replicator.
Keep foreign objects out of the docking port. A pin or similar object
can damage the circuitry of the computer.
Memory module
cover
Some models are equipped with the memory
module cover. The memory module slot under
this cover allows for the installation, replacement
and removal of additional memory module.
4GB or 8GB memory modules can be installed in
the computer's two memory slots for a maximum
of 16GB system memory. The actual amount of
useable system memory is less than the installed
memory modules.
Refer to the Additional memory module section.
Front with the display open
This section shows the computer with the display panel open. In order to
open the display, lift up the display panel and position it at a comfortable
viewing angle for you.
