Toshiba TECRA C50-C Series User Manual

Use a point size 0 Phillips screwdriver to remove and fasten the screws.
The use of an incorrect screwdriver can damage the screw heads.
Installing a memory module
To install a memory module, do the following:
1. Click Start. Point to the arrow ( ) beside the Shut down button and
then click Shut down. Ensure that the Power indicator is off.
2. Remove the AC adaptor, all cables, and peripherals connected to the
computer.
3. Close the display panel.
4. Turn the computer upside down and remove the battery pack.
5. Loosen the screw securing the memory module cover in place. Note
that the screw is attached to the cover in order to prevent it from being
lost.
6. Slide your fingernail or a thin object under the cover and lift it off.
Figure 4-9 Removing the memory module cover
1
2
1. Screw 2. Memory module cover
User's Manual 4-27

Toshiba TECRA C50-C Series Specifications

General

CPU	Intel Core i3/i5/i7
Processor	Intel Core i3/i5/i7
RAM	Up to 16GB DDR3L
Storage	Up to 500GB HDD, Up to 256GB SSD
Display	15.6" HD or FHD (1920 x 1080)
Graphics	Intel HD Graphics
Operating System	Windows 10 Pro
Ports	USB 3.0, USB 2.0, HDMI, VGA, Ethernet, SD card reader, headphone/microphone combo jack
Weight	2.3 kg (5.07 lbs)
