Toshiba TOSDIC-CIE DS Programming Manual

1.Outline
3
1.2. Basic specification
The basic specification of type1 light is described in Table 1.1.
Table 1.1 Unified Controller nv series type1 light
Item
Specifications
Supported Model
Unified Controller nv series type1 light *1)
Single : PUM11/12/14, PUM12/14 and EN651A *1)
Duplex : PUM14(Duplex), PUM14 and EN651 (Duplex) *2)
Communication System
pcmp
Collection (input) Data
Max.960 words (use of D register)
It sets up by PLC configuration registration of an PLCS engineering
tool.
Write(output) Data
use of D register
It sets up by tag registration of an engineering tool.
Set Data
Max.480 words (use of D register)
It sets up by PLC configuration registration of an PLCS engineering
tool.
Collection(input)
Parameter
Max.960 words (use of D register)
It sets up by Parameter configuration of an PLCS engineering tool.
*1) Moreover, you need the following versions to connect with a single type1 light.
PLCS Support Package V02.21 or newer
*2) Moreover, you need the following versions to connect with a duplex type1 light.
PLCS Support Package V02.23 or newer
PLC Server Service Control V02.21 or newer
PLCS Engineering Tool V02.55 or newer
