3.type1 light program sample
20
3.4.1 Registering a type1 light
The following alarm characters of system alarm are set when PLC is type1 light using
“User Defined System Alarm Name (PLC:SMART)” or User Defined System Alarm
Name (PLC:PLCS) of OIS-DS engineering tool.
• Group Name(PL?/P??)
System Tag
Caracters
DV0
Hard state
DV1
Soft state
DV2
TC-net I/O state
• Device Name(PL?DV?/P??DV?)
(DV0: Hard state)
System Tag
Caracters
System Tag
Caracters
HE0
CPU Relation
LE0
reserve
HE1
MEM Relation
LE1
reserve
HE2
G2 I/O Relation
LE2
G2 I/O Relation
HE3
TC-net I/O loop
LE3
TC-net I/O loop
HE4
G2I/O Degenerate
LE4
G2I/O Degenerate
HE5
-
LE5
-
HE6
TC-net I/O Error
LE6
TC-net I/O Error
HE7
-
LE7
-
HE8
-
LE8
-
HE9
-
LE9
-
HEA
Drive device
LEA
Drive device
HEB
TCnet Degenerate
LEB
TCnet Degenerate
HEC
Transmission
LEC
Transmission
HED
-
LED
-
HEE
-
LEE
Other (Hard)
HEF
Dupuli Relation
LEF
Dupuli Relation
