Toshiba TOSVERT VF-AS3 Option Instruction Manual

5
E6582171
Thank you for purchasing the Resolver option for TOSVERT VF-AS3 series inverter. This option is applicable as an
interface for resolver.
This manual contains instructions of this option.
<Description of the Encoder option>
Introduction
CAUTION
Mandatory
action
• Use the resolver with the specification described in this manual.
Improper resolver usage can result in accident and malfunction.
Important
Firmware compatibility
• VF-AS3 of CPU1 version “V106” or successor is applicable for this option.
Refer to inverter instruction manual for the check method of the CPU version.
VEC 010 Z 0
Revision number
Without cable
Encoder option type number
010: Resolver
Vector control with sensor compatible
