E6581611
F-13
6
<Frequency setting mode selection>
[Parameter setting]
Title Function Adjustment range Default setting
Frequency setting mode selection 1
0: Setting dial 1 (including extension panel
option) (save even if power is off)
1: Terminal VIA
2: Terminal VIB
3: Setting dial 2 (including extension panel
option) (press in center to save)
4: RS485 communication
5: UP/DOWN from external logic input
6: CANopen communication
7: Communication option
8: Terminal VIC
9, 10: -
11: Pulse train input
12, 13: -
14: sro
0
[Programmed value]
:
Setting dial 1
Frequencies are set by rotating the setting dial on the inverter and an extension
panel option. Like the position of notches in a volume knob, the frequency setting
value at the position of the notch is saved.
Refer to section 3.2.2
:
Terminal VIA
A frequency command is set by means of external analog signals.
(VIA terminal: 0 –10Vdc)
Refer to section 3.2.2 and 7.3
:
Terminal VIB
A frequency command is set by means of external analog signals.
(VIB terminal: 0 - +10Vdc or -10 - +10Vdc)
Refer to section 3.2.2 and 7.3
:
Setting dial 2
Frequencies are set by rotating the setting dial on the inverter and an extension
panel option. Press the center of the setting dial to save the frequency setting
value.
Refer to section 3.2.2
:
RS485
communication
Frequencies are set by RS485 communication from an external device.
Refer to section 6.38
:
UP/DOWN from
external logic input
Frequencies are set by up/down commands from a terminal.
Refer to section 6.10.4
:
CANopen
communication
Frequencies are set by CANopen communication from an external device.
Refer to “CANopen communication Instruction Manual E6581911”.
