Toshiba TOSVERT VFS15-4037PL-W User Manual

E6581611
J-6
10
(1)
Input AC reactor
(ACL)
Molded-case circuit breaker
MCCB
Power supply
Magnetic contactor
MC
Zero-phase reactor
core-type
radio noise
reduction filter
N.F
N.F
VF-S15
(4)
M
(7)
Braking resistor
Motor
Zero-phase reactor
core-type
radio noise
reduction filter
(5)
EMC noise reduction filter
(Compliant with European
standards)
(4)
(8)
Motor-end surge voltage
suppression filter
(for 500V models only)
(3) High-attenuation
radio noise
reduction filter
(6)
(9)
EMC Plate
DIN rail kit
(2)DC reactor
(DCL)
10.4 Optional external devices
The following external devices are optionally available for this inverter series.
(10) Parameter writer : RKP002Z
PWU003Z
(11) Extension panel : RKP007Z
(12) Remote control panel : CBVR-7B1
(13) Frequency meter : QS60T
(14) FRH kit : FRH KIT
(15) USB communication converter : USB001Z
(16) CC-Link communication option : CCL003Z
(17) PROFIBUS DP communication option :
PDP003Z
(18) DeviceNet communication option : DEV003Z
(19) EtherNet / IP-Modbus TCP communication option
: IPE002Z
(20) EtherCAT communication option : IPE003Z
(21) CANopen communication option : CAN001Z
: CAN002Z
: CAN003Z
(22) Communication option adaptor : SBP009Z
