Toshiba TOSVERT VFS15-4037PL-W User Manual

E6581611
K-28
11
 Factory specific parameters
Title Function Reference

Factory specific coefficient *3
*3: Factory specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
 Communication option parameters
Title Function Reference
, c885-c896,

Communication option common parameters Note 1)
48
CC-Link option parameters E6581830

PROFIBUS DP option parameters
E6581738

DeviceNet option parameters
E6581737
, 
EtherCAT option parameters
E6581818

EtherNet common parameters
E6581741

EtherNet/IP option parameters

Modbus TCP option parameters
, 
CANopen communication parameters E6581911
Note 1) Refer to each Instruction Manual for option about detailed specifications and common parameters.
11.4 Default settings by inverter rating
Inverter type
Torque
boost value
Dynamic
braking
resistance
Dynamic
braking
resistor
capacity
Automatic
torque
boost value
Motor rated
capacity
Motor rated
current
Motor
no-load
current
Over-
voltage stall
protection
level
Integrating
wattmeter
display unit
selection
／

(%)

(Ω)

(kW)

(%)

(kW)

(A)

(%)

(%)

VFS15-2004PM-W 6.0 200.0 0.12 6.2 0.40 2.00 65 136 0
VFS15-2007PM-W 6.0 200.0 0.12 5.8 0.75 3.40 60 136 0
VFS15-2015PM-W 6.0 75.0 0.12 4.3 1.50 6.20 55 136 0
VFS15-2022PM-W 5.0 75.0 0.12 4.1 2.20 8.90 52 136 0
VFS15-2037PM-W*1 5.0 40.0 0.12 3.4 4.00 14.80 48 136 1
VFS15-2055PM-W 4.0 15.0 0.44 3.0 5.50 21.00 46 136 1
VFS15-2075PM-W 3.0 15.0 0.44 2.5 7.50 28.20 43 136 1
VFS15-2110PM-W 2.0 7.5 0.88 2.3 11.00 40.60 41 136 1
VFS15-2150PM-W 2.0 7.5 0.88 2.0 15.00 54.60 38 136 1
VFS15S-2002PL-W 6.0 200.0 0.12 8.3 0.20 1.20 70 136 0
VFS15S-2004PL-W 6.0 200.0 0.12 6.2 0.40 2.00 65 136 0
VFS15S-2007PL-W 6.0 200.0 0.12 5.8 0.75 3.40 60 136 0
VFS15S-2015PL-W 6.0 75.0 0.12 4.3 1.50 6.20 55 136 0
VFS15S-2022PL-W 5.0 75.0 0.12 4.1 2.20 8.90 52 136 0
VFS15-4004PL-W 6.0 200.0 0.12 6.2 0.40 1.00 65 141 0
VFS15-4007PL-W 6.0 200.0 0.12 5.8 0.75 1.70 60 141 0
VFS15-4015PL-W 6.0 200.0 0.12 4.3 1.50 3.10 55 141 0
VFS15-4022PL-W 5.0 200.0 0.12 4.1 2.20 4.50 52 141 0
VFS15-4037PL-W*1 5.0 160.0 0.12 3.4 4.00 7.40 48 141 1
VFS15-4055PL-W 4.0 60.0 0.44 2.6 5.50 10.50 46 141 1
VFS15-4075PL-W 3.0 60.0 0.44 2.3 7.50 14.10 43 141 1
VFS15-4110PL-W 2.0 30.0 0.88 2.2 11.00 20.30 41 141 1
VFS15-4150PL-W 2.0 30.0 0.88 1.9 15.00 27.30 38 141 1
*1: When region setting is JP,  is set to 3.7(kW).
