2) Optional dynamic braking resistors
Optional dynamic braking resistors are listed below. All these resistors are 3%ED in operation rate
Inverter type
Braking resistor
Type-form Rating
Continuous
regenerative braking
allowable capacity
VFS15-2004PM-W, 2007PM-W
VFS15S-2002PL-W~2007PL-W
PBR-2007
120W-200
90W
VFS15-2015PM-W, 2022PM-W
VFS15S-2015PL-W, 2022PL-W
PBR-2022
120W-75
90W
VFS15-2037PM-W
PBR-2037 120W-40

90W
VFS15-2055PM-W, 2075PM-W PBR7-004W015 440W-15

130W
VFS15-2110PM-W, 2150PM-W PBR7-008W7R5 880W-7.5

270W
VFS15-4004PL-W~4022PL-W PBR-2007 120W-200

90W
VFS15-4037PL-W PBR-4037 120W-160

90W
VFS15-4055PL-W, 4075PL-W PBR7-004W060 440W-60

130W
VFS15-4110PL-W, 4150PL-W PBR7-008W030 880W-30

270W
Note 1: The data in Rating above refer to the resultant resistance capacities (watts) and resultant resistance
values (Ω).
Note 2: Braking resistors for frequent regenerative braking are optionally available. For more information,
contact your Toshiba distributor.
Note 3: Type-form of “PBR-” indicates the thermal fuse”. Type-form of “PBR7-“ indicates the thermal fuse
and thermal relay.
Note 4: The default setting values of parameter f308 (Dynamic braking resistance) and f309 (Dynamic
braking resistor capacity) are applied to braking resistor option.
3) Minimum resistances of connectable braking resistors
The minimum allowable resistance values of the externally connectable braking resistors are listed in the
table below.
Do not connect braking resistors with smaller resultant resistances than the listed minimum allowable
resistance values.
Inverter rated
output capacity
(kW)
240V Class 500V Class
Resistance
of standard
option
Minimum
allowable
resistance
Resistance
of standard
option
Minimum
allowable
resistance
0.2
200 55
- -
0.4
200 55 200 114
0.75
200 55 200 114
1.5
75 44 200 67
2.2
75 33 200 67
4.0
40Ω 16Ω
160 54
5.5
15Ω 12Ω
60 43
7.5
15Ω 12Ω
60 28
11
7.5Ω 5Ω
30 16
15
7.5Ω 5Ω
30 16
Note: Be sure to set f308 (Dynamic braking resistance) at the resistance of the dynamic braking resistor
connected.
