E6581611
F-79
6
Function
Process control including keeping airflow, pressure, and the amount of flow constant, can be
exercised using feedback signals (4 to 20mA, 0 to 10V) from a detector.
Or, it is also possible to always set 0 for integral and differential at terminal input.
Refer to "PID control instruction manual: E6581879” for details.
[Parameter setting]
Title Function Adjustment range Default setting
fpid
Process input value of PID control f368 - (Hz) 0.0
f359
PID control waiting time 0-2400 (s) 0
f360
PID control
0: Disabled
1: Process type PID control
2: Speed type PID control
0
f361
Delay filter 0.0-25.0 (s) 0.1
f362
Proportional gain 0.01-100.0 0.30
f363
Integral gain 0.01-100.0 0.20
f366
Differential gain 0.00-2.55 0.00
f367
Process upper limit 0.0-fh (Hz) 60.0 *1
f368
Process lower limit 0.0- (Hz) 0.0
f369
PID control feedback signal selection
0: Disabled
1: Terminal VIA
2: Terminal VIB
3: Terminal VIC
4 to 6: -
0
f372
Process increasing rate (speed type
PID control)
0.1-600.0 (s) 10.0
f373
Process decreasing rate (speed type
PID control)
0.1-600.0 (s) 10.0
f380
PID forward/reverse characteristics
selection
0: Forward
1: Reverse
0
f389
PID control reference signal selection
0: fmod / f207 selected
1: Terminal VIA
2: Terminal VIB
3: fpid
4: RS485 communication
5: UP/DOWN from external logic
input
6: CANopen communication
7: Communication option
8: Terminal VIC
9, 10: -
11: Pulse train input
0
*1: Default setting value vary depending on the setup menu setting. Refer to section 11.5.
