6.33.3 Calibration of analog output
f681 : Analog output signal selection
f684 : Analog output filter
f691 : Inclination characteristic of analog output
f692 : Analog output bias
 Function
Output signal from the FM terminal can be switched between 0 to 1mAdc output, 0 to 20mAdc output,
and 0 to 10Vdc output with the
f681 setting. The standard setting is 0 to 1mAdc output.
* Optional frequency meter: When using QS60T, set
f681=0 (meter option (0 to 1mA) output).
[Parameter setting]
Title Function Adjustment range Default setting
f681
Analog output signal selection
0: Meter option (0 to 1mA)
1: Current (0 to 20mA) output
2: Voltage (0 to 10V) output
0
f684
Analog output filter
2-1000 (ms) 2
f691
Inclination characteristic of analog
output
0: Negative inclination (downward slope)
1: Positive inclination (upward slope)
1
f692
Analog output bias -1.0 - +100.0 (%) 0.0
Note 1: In case of 0 to 20mAdc (4 to 20mAdc) output, or 0 to 10Vdc output, set f681 to 1 or 2.
In case of 4 to 20mAdc output,
f692 needs adjustment.
