Toshiba TOSVERT VFS15-4037PL-W User Manual

E6581611
H-10
8
Parameter Setting No. LED display Function Unit
Communication No.

to ,
f720

0
x60.0
Output frequency Hz / free unit FE00
1
c16.5
Output current *1 % / A FC02
2
f50.0
Frequency command value Hz / free unit FE02
3
y100
Input voltage (DC detection) *1
% / V FC05
4
p 90
Output voltage (command value) *1 % / V FC08
5
k 3.0
Input power *1 kW FC06
6
h 2.8
Output power *1 kW FC07
7
q 80
Torque *1, *2 % FC04
9
g 60
Motor cumulative load factor % FE23
10
l 80
Inverter cumulative load factor % FE24
11
r 80
PBR (Braking resistor) cumulative load factor % FE25
12
b51.0
Stator frequency
Hz / free unit FE15
13
a 65
VIA input value
% FE35
14
b 45
VIB input value *2
% FE36
18
*3
Arbitrary code from communication
*3 *3
20
c 35
VIC input value
% FE37
21
p800
Pulse train input value
pps FE56
23
d40.0
PID feedback value
Hz / free unit FE22
24
k356
Integral input power
Depend on
f749
FE76
25
h348
Integral output power
Depend on
f749
FE77
26
g 75
Motor load factor
% FE26
27
l 70
Inverter load factor
% FE27
28
a33.0
Inverter rated current
A FE70
29
f 70
FM output value
% FE40
30
p800
Pulse train output value
pps FD40
31
p34.5
Cumulative power on time
100 hours FE80
32
f28.6
Cumulative fan operation time
100 hours FD41
33
t27.7
Cumulative operation time
100 hours FD14
34
n89.0
Number of starting times
10000 times FD32
35
f45.5
Forward number of starting times
10000 times FD33
36
r43.5
Reverse number of starting times
10000 times FD34
37
a 2
Number of trip
times FD35
40
a33.0
Inverter rated current (Carrier frequency
corrected)
A FD70
52
w50.0
During stop : Frequency command value
During operation : Output frequency
Hz / free unit FE99
