E6581611
K-35
11
 Table of output terminal functions 2
Function
No.
Code Function Action Reference
30 POLR Braking resistor overload pre-alarm ON: 50% or more of calculated value of  set
overload protection level
OFF: Less than 50% of calculated value of  set
overload protection level
6.19.4
31 POLRN Inversion of braking resistor overload pre-
alarm
Inversion of POLR
40 RUN Run/stop ON: While operation frequency is output or DC braking is in
operation ()
OFF: Operation stopped
7.2.2
41 RUNN Inversion of run/stop Inversion of RUN
42 HFL Serious failure ON: At trip *2
OFF: Other than those trip above
43 HFLN Inversion of serious failure Inversion of HFL
44 LFL Light failure ON: At trip (~, ~, , ~, )
OFF: Other than those trip above
45 LFLN Inversion of light failure Inversion of LFL
50 FAN Cooling fan ON/OFF ON: Cooling fan is in operation
OFF: Cooling fan is off operation
6.29.11
51 FANN Inversion of cooling fan ON/OFF Inversion of FAN
52 JOG In jogging operation ON: In jogging operation
OFF: Other than jogging operation
6.14
53 JOGN Inversion of in jogging operation Inversion of JOG
54 JBM Operation panel / terminal block operation ON: At terminal block operation command
OFF: Other than those operation above
6.2.1
55 JBMN Inversion of operation panel/terminal block
operation
Inversion of JBM
56 COT Cumulative operation time alarm ON: Cumulative operation time is  or more
OFF: The cumulative operation time is less than 
6.29.12
57 COTN Inversion of cumulative operation time alarm Inversion of COT
58 COMOP Communication option communication error ON: Communication error of communication option occurs
OFF: Other than those above
6.38
59 COMOPN Inversion of communication option
communication error
Inversion of COMOP
60 FR Forward/reverse run ON: Reverse run
OFF: Forward run
(Operation command state is output while motor operation is
stopped. No command is to OFF.)
7.2.2
61 FRN Inversion of forward/reverse run Inversion of FR
62 RDY1 Ready for operation 1 ON: Ready for operation (with ST / RUN)
OFF: Other than those above
63 RDY1N Inversion of ready for operation 1 Inversion of RDY1
64 RDY2 Ready for operation 2 ON: Ready for operation (without ST / RUN)
OFF: Other than those above
65 RDY2N Inversion of ready for operation 2 Inversion of RDY2
68 BR Brake release ON: Brake exciting signal
OFF: Brake releasing signal
6.22
69 BRN Inversion of brake release Inversion of BR
70 PAL Pre-alarm ON: One of the following is turned on
ON POL, POHR, POT, MOFF, UC, OT, LL stop, COT,
and momentary power failure deceleration stop.
Or , , ,  issues an alarm
OFF: Other than those above
7.2.2
71 PALN Inversion of pre-alarm Inversion of PAL
78 COME RS485 communication error ON: Communication error occurred
OFF: Communication works
6.38
79 COMEN Inversion of RS485 communication error Inversion of COME
*2: At trip , , , , , , , , , , ~, ~, , ,
, ~, , , , , ~, , , , , .
