E6581611
K-37
11
Table of output terminal functions 4
Function
No.
Code Function Action Reference
144 PIDF Signal in accordance of frequency command ON: Frequency commanded by and are
within ±.
OFF: Other than those above
6.24
145 PIDFN Inversion of signal in accordance of
frequency command
Inversion of PIDF
146 FLR Fault signal (output also at a retry waiting) ON: While inverter is tripped or retried
OFF: While inverter is not tripped and not retried
6.19.3
147 FLRN Inversion of fault signal (output also at a
retry waiting)
Inversion of FLR
150 PTCA PTC input alarm signal ON: PTC thermal input value is f646 or more
OFF: PTC thermal input value is less than f646
6.29.16
151 PTCAN Inversion of PTC input alarm signal Inversion of PTCA
152, 153 Factory specific coefficient - *1
154 DISK Analog input break detection alarm ON: VIB terminal input value is f633 or less
OFF: VIB terminal input value is more than f633
6.29.14
155 DISKN Inversion of analog input break detection
alarm
Inversion of DISK
156 LI1 F terminal status ON: F terminal is ON status
OFF: F terminal is OFF status
7.2.2
157 LI1N Inversion of F terminal status Inversion of LI1
158 LI2 R terminal status ON: R terminal is ON status
OFF: R terminal is OFF status
159 LI2N Inversion of R terminal status Inversion of LI2
160 LTAF Cooling fan replacement alarm ON: Cooling fan reaches parts replacement time
OFF: Cooling fan does not reach parts replacement time
6.29.15
161 LTAFN Inversion of cooling fan replacement alarm Inversion of LTAF
162 NSA Number of starting alarm ON: Number of starting alarm is f648 or more
OFF: Number of starting alarm is less than f648
6.29.17
163 NSAN Inversion of number of starting alarm Inversion of NSA
166 DACC Acceleration operation in progress ON: Acceleration operation in progress
OFF: Other than those above
7.2.2
167 DACCN Inversion of acceleration operation in
progress
Inversion of DACC
168 DDEC Deceleration operation in progress ON: Deceleration operation in progress
OFF: Other than those above
169 DDECN Inversion of deceleration operation in
progress
Inversion of DDEC
170 DRUN Constant speed operation in progress ON: Constant speed operation in progress
OFF: Other than those above
171 DRUNN Inversion of constant speed operation in
progress
Inversion of DRUN
172 DDC DC braking in progress ON: DC braking in progress
OFF: Other than those above
6.12.1
173 DDCN Inversion of DC braking in progress Inversion of DDC
174 to 179 Factory specific coefficient - *1
180 IPU Integral input power pulse output signal ON: Integral input power unit reach
OFF: Other than those above
6.33.1
182 SMPA Shock monitoring pre-alarm signal ON: Current / torque value reach the shock monitoring
detection condition
OFF: Other than those above
6.28
183 SMPAN
Inversion of
shock monitoring pre-alarm
signal
Inversion of SMPA
222 to 253 Factory specific coefficient - *1
254 AOFF Always OFF Always OFF 7.2.2
255 AON Always ON Always ON
*1: Factory specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
Note 1: As function No. that are not described in the table above are assigned "No function", output signal is always “OFF” at
even number, output signal is always “ON” at odd number.
