(3) Removing the outside terminal block cover (VFS15-2015PM-W to 2037PM-W, VFS15S-2015PL-W, 2022PL-W,
VFS15-4004PL-W to 4037PL-W)
● After wiring is complete, be sure to restore the terminal cover to its original position.
1)
2)
3)
Insert a screwdriver or other thin object into the
hole indicated with the
mark.
Press in on the screwdriver.
While pressing on the screwdriver, sidles the
terminal cover downward to remove it.
