For instruction in the United States, Integral solid state short circuit protection does not provide branch circuit
protection. Branch circuit protection must be provided in accordance with the National Electrical Code and any
additional local codes.
For instruction in the Canada, Integral solid state short circuit protection does not provide branch circuit protection.
Branch circuit protection must be provided in accordance with the Canadian Electrical Code and any additional
local codes.
9.2.3 Compliance with Peripheral devices
Use the UL listed fuses at connecting to power supply.
Short circuit test is performed under the condition of the power supply short-circuit currents in below.
These interrupting capacities and fuse rating currents depend on the applicable motor capacities.
 AIC, Fuse and Wire sizes
Inverter model
Voltage
(V)
Input
withstand
rating (kA)
Output
Interrupt
rating (kA)
Branch circuit
protection
Rating
(A)
Cable sizes of
power circuit
Earth Cable
Markig Y (1) X (2) Z1 Z2 - -
VFS15-2004PM-W 240 5 5 Class CC 7 AWG 14 AWG 14
VFS15-2007PM-W 240 5 5 Class J 15 AWG 14 AWG 14
VFS15-2015PM-W 240 5 5 Class J 25 AWG 14 AWG 14
VFS15-2022PM-W 240 5 5 Class J 25 AWG 12 AWG 14
VFS15-2037PM-W 240 5 5 Class J 45 AWG 10 AWG 10
VFS15-2055PM-W 240 22 5 Class J 60 AWG 8 AWG 10
VFS15-2075PM-W 240 22 5 Class J 70 AWG 6 AWG 10
VFS15-2110PM-W 240 22 5 Class J 100 AWG 6*2 AWG 8
VFS15-2150PM-W 240 22 5 Class J 110 AWG 6*2 AWG 8
VFS15S-2002PL-W 240 1 5 Class CC 7 AWG 14 AWG 14
VFS15S-2004PL-W 240 1 5 Class J 15 AWG 14 AWG 14
VFS15S-2007PL-W 240 1 5 Class J 25 AWG 14 AWG 14
VFS15S-2015PL-W 240 1 5 Class J 40 AWG 10 AWG 12
VFS15S-2022PL-W 240 1 5 Class J 45 AWG 10 AWG 10
VFS15-4004PL-W 500 5 5 Class CC 6 AWG 14 AWG 14
VFS15-4007PL-W 500 5 5 Class CC 6 AWG 14 AWG 14
VFS15-4015PL-W 500 5 5 Class CC 12 AWG 14 AWG 14
VFS15-4022PL-W 500 5 5 Class J 15 AWG 14 AWG 14
VFS15-4037PL-W 500 5 5 Class J 25 AWG 12 AWG 14
VFS15-4055PL-W 500 22 5 Class J 40 AWG 10 AWG 10
VFS15-4075PL-W 500 22 5 Class J 40 AWG 8 AWG 10
VFS15-4110PL-W 500 22 5 Class J 60 AWG 8 AWG 10
VFS15-4150PL-W 500 22 5 Class J 70 AWG 6 AWG 10
