Toshiba TOSVERT VFS15-4075PL-W User Manual

E6581611
I-8
9
Suitable for use on a circuit capable of delivering not more than___X___rms symmetrical kilo Amperes,___Y___Volts
maximum, when protected by___Z1___with a maximum rating of___Z2___.
(1) Input withstand rating is that for which the product has been designed thermally. Installation on a supply greater than
this level will require additional inductance to satisfy this level.
(2) Output interrupt rating relies on Integral solid state short circuit protection. This does not provide branch circuit
protection. Branch circuit protection must be provided in accordance with the National Electrical Code and any
additional local codes. This is dependant on the type of installation.
In case of using VF-S15 with a higher AIC capability up to 100kA(*1), install the minimum input inductance or
more listed in the following table. The Short Circuit Current Ratings (SCCR) become 100kA(*1) by installing VF-
S15 with the circuit breakers(GV3P) or the fuses listed in the following table.
 AIC 100kA, Branch circuit protection and Wire sizes
Inverter model
Minimum
input
Inductance
(mH)
Branch circuit protection
Cable
sizes of
power
circuit
Earth Cable
With Fuses
(Bussman
/Ferraz)
Fuse
Rating
(A)
With circuit
breakers
(Schneider)
Breaker
Setting
(A)
VFS15-2004PM-W 0.05 Class J 10 GV3P13 9 AWG 14 AWG 14
VFS15-2007PM-W 0.05 Class J 15 GV3P13 9 AWG 14 AWG 14
VFS15-2015PM-W 0.05 Class J 25 GV3P13 10 AWG 14 AWG 14
VFS15-2022PM-W 0.05 Class J 25 GV3P18 18 AWG 12 AWG 14
VFS15-2037PM-W 0.05 Class J 45 GV3P25 25 AWG 10 AWG 10
VFS15-2055PM-W 0.02 Class J 60 GV3P40 40 AWG 8 AWG 10
VFS15-2075PM-W 0.02 Class J 70 GV3P50 50 AWG 6 AWG 10
VFS15-2110PM-W 0.02 Class J 100 GV3P65 65 AWG 6*2 AWG 8
VFS15-2150PM-W 0.02 Class J 110 AWG 6*2 AWG 8
VFS15S-2002PL-W 0.28 Class J 10 GV3P13 9 AWG 14 AWG 14
VFS15S-2004PL-W 0.28 Class J 15 GV3P13 9 AWG 14 AWG 14
VFS15S-2007PL-W 0.28 Class J 25 GV3P13 13 AWG 14 AWG 14
VFS15S-2015PL-W 0.28 Class J 40 GV3P25 25 AWG 10 AWG 12
VFS15S-2022PL-W 0.28 Class J 45 GV3P32 32 AWG 10 AWG 10
VFS15-4004PL-W 0.10 Class J 6 GV3P13 9 AWG 14 AWG 14
VFS15-4007PL-W 0.10 Class J 6 GV3P13 9 AWG 14 AWG 14
VFS15-4015PL-W 0.10 Class J 15 GV3P13 9 AWG 14 AWG 14
VFS15-4022PL-W 0.10 Class J 15 GV3P13 10 AWG 14 AWG 14
VFS15-4037PL-W 0.10 Class J 25 GV3P13 13 AWG 12 AWG 14
VFS15-4055PL-W 0.03 Class J 40 GV3P18 18 AWG 10 AWG 10
VFS15-4075PL-W 0.03 Class J 40 GV3P25 25 AWG 8 AWG 10
VFS15-4110PL-W 0.03 Class J 60 GV3P32 32 AWG 8 AWG 10
VFS15-4150PL-W 0.03 Class J 70 GV3P40 (*1) 40 AWG 6 AWG 10
(*1) In case VFS15-4150PL-W with the circuit breaker, the Short Circuit Current Ratings (SCCR) is 65kA, not 100kA.
