Toshiba TOSVERT VFS15-4075PL-W User Manual

E6581611
A-18
1
Shorting-bar
M5 screw
Grounding capacitor switch
(4055PL-W, 4075PL-W only)
For EMC plate
Grounding terminal
(M5 screw)
Grounding terminal
(M5 screw)
Shorting-bar
M6 screw
For EMC plate
Grounding terminal
(M5 screw)
Grounding terminal
(M5 screw)
VFS15-2055PM-W, 2075PM-W
VFS15-4055PL-W, 4075PL-W
VFS15-2110PM-W, 2150PM-W
Note1) Bend the clips on the wiring port of the terminal cover to connect the PB, PO, PA/+, and PC/- terminals.
Note2) Be careful to insert all wires into the cage of terminal block.
