E6581611
A-19
1
Shorting-bar
Grounding capacitor
switch
For EMC plate
M5 screw
Grounding terminal
(M5 screw)
Grounding terminal
(M5 screw)
VFS15-4110PL-W, 4150PL-W
Note1) Bend the clips on the wiring port of the terminal cover to connect the PB, PO, PA/+, and PC/- terminals.
Note2) Be careful to insert all wires into the cage of terminal block.
