E6581611
K-18
11
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
0627 Undervoltage
trip/alarm
selection
- - 0: Alarm only(detection level 60% or less)
1: Tripping (detection level 60% or less)
2: Alarm only(detection level 50% or
less, input AC or DC reactor required)
3: -
0
6.29.13
0629 Factory specific
coefficient 6B
- - - -
* 3
0631 Inverter overload
detection method
- - 0: 150%-60s (120%-60s)
1: Temperature estimation
0
5.6
0632 Electronic-thermal
memory
- - 0: Disabled (thr, f173)
1: Enabled (thr, f173)
2: Disabled (thr)
3: Enabled (thr)
0
5.6
6.29.1
0633 Analog input break
detection level (VIC)
% 1/1 0: Disabled,
1-100
0
6.29.14
0634 Annual average
ambient
temperature (parts
replacement
alarms)
- - 1: -10 to +10C
2: 11-20C
3: 21-30C
4: 31-40C
5: 41-50C
6: 51-60C
3
6.29.15
0643
Factory specific
coefficient 6C
- - - -
* 3
0644
Operation
selection of
analog input break
detection (VIC)
- - 0: Tripping
1: Alarm only (Coast stop)
2: Alarm only (f649 frequency)
3: Alarm only (Maintain running)
4: Alarm only (Deceleration stop)
0
6.29.14
0645
PTC thermal
selection
- - 1: Tripping
2: Alarm only
1
6.29.16
0646
PTC detection
resistor value
Ω 1/1
100-9999 3000
0648
Number of starting
alarm
10000
times
0.1/0.1 0.0-999.0
999.0
6.29.17
0649
Fallback frequency
Hz 0.1/0.01 ll- 0.0
6.29.14
0650 Forced fire-speed
control selection
- - 0: Disabled
1: Enabled
0
6.30
0656
Factory specific
coefficient 6D
- - - -
* 3
0657 Overload alarm level
% 1/1
10-100
50
5.6
0660 Override addition
input selection
- -
0: Disabled
1: Terminal VIA
2: Terminal VIB
3: Terminal VIC
4: fc
0
6.31
0661 Override
multiplication input
selection
- -
0: Disabled
1: Terminal VIA
2: Terminal VIB
3: Terminal VIC
4: f729
0
0663 Analog input
terminal function
selection (VIB)
- - 0: Frequency command
1: Acceleration/deceleration time
2: Upper limit frequency
3, 4: -
5: Torque boost value
6: Stall prevention level
7: Motor electronic-thermal protection
level
8 to 10: -
11: Base frequency voltage
0
6.32
*2: Default setting values vary depending on the capacity. Refer to section 11.4.
*3: Factory specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
