E6581611
K-17
11
Protection parameters
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
0601 Stall prevention
level 1
%
(A)
1/1
10-199, *12
200 (disabled)
150
6.29.2
0602
Inverter trip
retention selection
- - 0: Cleared with power off
1: Retained with power off
0
6.29.3
0603 Emergency stop
selection
- - 0: Coast stop
1: Deceleration stop
2: Emergency DC braking
3: Deceleration stop (f515)
4: Quick deceleration stop
5: Dynamic quick deceleration stop
0
6.29.4
0604 DC braking time
during emergency
stop
s 0.1/0.1
0.0-20.0 1.0
0605
Output phase
failure detection
selection
-
-
0: Disabled
1: At start-up (only one time after
power on)
2: At start-up (each time)
3: During operation
4: At start-up + during operation
5: Detection of cutoff on output side
0
6.29.5
0607 Motor 150%
overload detection
time
s 1/1 10-2400 300
5.6
6.29.1
0608 Input phase failure
detection selection
- - 0: Disabled
1: Enabled
1
6.29.6
0609 Small current
detection hysteresis
% 1/1 1-20 10
6.29.7
0610 Small current
trip/alarm selection
- - 0: Alarm only
1: Tripping
0
0611 Small current
detection current
%
(A)
1/1 0-150 *12 0
0612 Small current
detection time
s 1/1 0-255 0
0613 Detection of
output short-circuit
at start-up
- - 0: Each time (standard pulse)
1: Only one time after power on
(standard pulse)
2: Each time (short pulse)
3: Only one time after power on
(short pulse)
0
6.29.8
0614 Ground fault
detection selection
- -
0: Disabled
1: Enabled
1
6.29.9
0615 Over-torque
trip/alarm selection
- - 0: Alarm only
1: Tripping
0
6.29.10
0616 Over-torque
detection level
%
1/0.01 0 (disabled)
1-250
150
0618 Over-torque
detection time
s 0.1/0.1 0.0-10.0 0.5
0619 Over-torque
detection hysteresis
% 1/0.01 0-100 10
0620 Cooling fan
ON/OFF control
-
- 0: ON/OFF control
1: Always ON
2-7: -
0
6.29.11
0621 Cumulative
operation time
alarm setting
100
hours
0.1/0.1
(=10 hours)
0.0-999.0 876.0
6.29.12
0625
Factory specific
coefficient 6A
- - - -
*3
0626 Over-voltage stall
protection level
%
1/1 100-150 *2
6.19.4
6.19.5
*3: Factory specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
*12: When f701=1, adjustment range is 100%=rated current, or 100%=200V(240V class)/ 400V(500V class).
