Toshiba TOSVERT VFS15-4075PL-W User Manual

E6581611
K-25
11
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference

0778 Easy setting mode
parameter 28
- -
0-2999
(Set by communication number)
999 4.5
6.37

0779 Easy setting mode
parameter 29
- - 999

0780 Easy setting mode
parameter 30
- - 999

0781 Easy setting mode
parameter 31
- - 701
(F701)

0782 Easy setting mode
parameter 32
- - 50
(PSEL)

0790 Panel display
selection at power
on
- - 0: hello
1: f791 to f794
2, 3: -
0 6.34.10

0791 1
s
t
and 2
n
d
characters of
f790
hex - 0-FFFF 2d2d

0792 3
r
d
and 4
th
characters of
f790
hex - 0-FFFF 2d2d

0793 5
th
and 6
th
characters of
f790
hex - 0-FFFF 2d2d

0794 7
th
and 8
th
characters of
f790
hex - 0-FFFF 2d2d

0799 Factory specific
coefficient 7A
- - - - *3
*3: Factory specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
 Communication parameters
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference

0800
Baud rate - - 3: 9600bps
4: 19200bps
5: 38400bps
4 6.38.1

0801
Parity - - 0: No parity
1: Even parity
2: Odd parity
1

0802
Inverter number - 1/1 0-247 0

0803
Communication
time-out time
s 0.1/0.1 0.0: Disabled,
0.1-100.0
0.0

0804
Communication
time-out action
- - 0: Alarm only
1: Trip (Coast stop)
2: Trip (Deceleration stop)
0

0805
Communication
waiting time
s 0.01/0.01 0.00-2.00 0.00

0806
Setting of master
and slave for
communication
between inverters
- - 0: Slave (0 Hz command issued in
case the master inverter fails)
1: Slave (Operation continued in case
the master inverter fails)
2: Slave (Emergency stop tripping in
case the master inverter fails)
3: Master (transmission of frequency
commands)
4: Master (transmission of output
frequency signals)
0

0808
Communication
time-out detection
condition
- - 0: Valid at any time
1: Communication selection of
fmod or cmod
2: 1 + during operation
1
