E6581611
K-26
11
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
0810
Communication
command point
selection
- 1/1 0: Disabled
1: Enabled
0 6.10.2
6.38.1
0811
Communication
command point 1
setting
% 1/1 0-100 0
0812
Communication
command point 1
frequency
Hz 0.1/0.01 0.0- 0.0
0813
Communication
command point 2
setting
% 1/1 0-100 100
0814
Communication
command point 2
frequency
Hz 0.1/0.01 0.0- *1
0829
Selection of
communication
protocol
- - 0: Toshiba inverter protocol
1: Modbus RTU protocol
0 6.38.1
0856 Number of motor
poles for
communication
- - 1: 2 poles
2: 4 poles
3: 6 poles
4: 8 poles
5: 10 poles
6: 12 poles
7: 14 poles
8: 16 poles
2
0870
Block write data 1 - - 0: No selection
1: Communication command 1
2: Communication command 2
3: Frequency command value
4: Output data on the terminal block
5: FM analog output
6: Motor speed command
0
0871
Block write data 2 - - 0
0875
Block read data 1 - - 0: No selection
1: Status information 1
2: Output frequency
3: Output current
4: Output voltage
5: Alarm information
6: PID feedback value
7: Input terminal monitor
8: Output terminal monitor
9: Terminal VIA monitor
10: Terminal VIB monitor
11: Terminal VIC monitor
12: Input voltage (DC detection)
13: Motor speed
14: Torque
0
0876
Block read data 2 - - 0
0877
Block read data 3 - - 0
0878
Block read data 4 - - 0
0879
Block read data 5 - - 0
0880
Free notes - 1/1 0-65530 (65535) 0 6.38.3
0898
Factory specific
coefficient 8A
- - - - *3
0899
Communication
function reset
- - 0: -
1: Reset (after execution: 0)
0 6.38.1
*1: Default setting values vary depending on the setup menu setting. Refer to section 11.5.
*3: Factory specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
