“Click”
Assembly:
Align the bottom of the dirty water
tank with the dirty water tank cavity,
hold the dirty water tank and push it
inwards until you hear a "click" sound.
4. Brush Guard
Disassembly:
Hold and press the brush guard lock
with your thumb and index, and lift
the brush guard lightly.
Assembly:
Align the brush guard with the spray hole,
hold and press the brush guard lock with
your thumb and index, and put the brush
guard on the brush base until you hear a
"click" sound.
5. Brush Roller
Disassembly:
Hold the roller brush handle, remove it
leftwards and take out the roller brush.
Assembly:
Hold the roller brush handle, align with the
roller brush shaft B, and put the handle back
into the base groove A.
ENGLISH 15
