13
Installing the Power Cord Hooks
1. Assemble the 2 power cord hooks on the back of the unit as shown below.
2. Screw the drain hose adapter into the
spout by twisting clockwise.
3. Insert the drainage hose into the drain
connector.
Note: When using the continuous drainage option, make sure that the air
conditioner is located on a flat, level surface and that the drain hose is directed
downwards and clear of any obstructions. Placing the air conditioner on an uneven
surface may result in the chassis filling with water until the H8 malfunction code is
displayed. If this occurs, empty the water in the chassis, then recheck the air
conditioner location and hose connection.
direction of wire hook is upward
direction of wire hook is downward
screw
wire hook
2. Wrap the power cord around the power cord hooks when not in use.
