14
Installing in Double-Hung Sash Windows
Note: If the width of your window is smaller than 20.5 inches, please remove the
adjusting panel from the window panel and then cut the window panel to make the
width of the window panel the same width as your window.
1. Assemble the rear clip by snapping the Joint B and Joint C together.
clasp
rear connector (lower)
rear connector (upper)
2. Snap the attached Joints B+C into place on the inner side of the window panel.
window panel
joint B+C
inner side
3. Attach the protective grill on the outer side of the window panel to Joint B+C
with included screws.
screws
protective grille
To Next Page
